Spindleless Rotary Log Wood Veneer Peeling Machine for Plywood Veneer Making Machine

Basic Info.

Model NO.	MH-VPM
Automatic	Semi-Automatic
Certification	CE
Weight	13ton
Power	61.2kw
Function	Veneer Manufacturing
Knife Type	with Hydraulic Knife Holder
Max Log Diameter	600mm
Thickness	0.8-3.5mm
Max Log Length	2600mm
Name	Wood Veneer Peeling Machine
Transport Package	Plastic Film
Specification	7200*2300*1500mm
Trademark	MINGHUNG
Origin	Linyi City, China
HS Code	846596
Production Capacity	1000sets/Year

Packaging & Delivery

Package Size 720.00cm * 230.00cm * 160.00cm Package Gross Weight 11000.000kg

Product Description

Spindleless Rotary Log Wood Veneer Peeling Machine for Plywood Veneer Making Machine
Hello friends, We are China MINGHUNG factory which produce peeling machine and plywood machine, share strong 8feet veneer peeling lathe with good hydraulic knife holder with you, this type peeling lathe are heavy and powerful to peel kinds of hardwood like beech, birch and can produce high accurate wood veneer. And this 2700mm veneer peeling lathe with hydraulic knife holder, so it through clamping knife by hydraulic system, therefore, when the knife become blunt and you want to take out and grinding it, or you need change new knife, it will become very easy and more convenient.For our strong 8feet log peeling lathe, it uses good materials and parts and accessories, so it is very heavy, and for the power, each main motor power is big, so it is powerful to peel wood. Except these advantages, we add the crane for peeling machine, thus it can lift the hydraulic knife holder easy, no need two workers to do it, because it is heavy. Now let me show you some detailed pictures of our powerful 8feet spindleless peeling machine with you,

How to estimate one set peeling machine quality are good or not? details will show everything. We are one China factory which insist using good materials, continuous to improve our plywood veneer machine, we insist offer good, suitable, and strong woodworking machine to our clients, and help their business become better and better.For the standard spindleless peeling machine, except 8feet peeling machine, we have 4feet wood peeling machine too, but we also can customize machine size according to your own requires and conditions, for example, we have some clients require 1600mm peeling machine, some require 1800mm peeling machine, some require 2000mm peeling machine. We will offer the suitable peeling machine for you.Except veneer peeling machine, for producing wood veneer, other machine like wood debarker, log conveyor, veneer stacker, blade sharpener also required, please watch below picture
The whole veneer production line, only require 1-2 workers are enough, it will process wood and produce wood veneer.

Name	Veneer peeling line
Max processing length	2600mm
Max processing diameter	600mm
Thickness range	0/5-3.5mm
Speed	46m/min
Power	60.2kw
Weight	11000 kgs

Our factory exported many plywood veneer machines to different country, some country require related CE documents, if you need too, please do not worry, we have the complete documents for you do custom clearance,
Except veneer peeling lathe, you may interested the magnetic blade sharpener and veneer dryer.
Welcome contact us for more information, we will share machine working video with you, offer more details and price to you.Best regardsSHANDONG MINGHUNG WOOD MACHINERY CO.,LTD
